STRATTA-V: Steel Radiator

stratta-v_1800x528-singledouble_ral_9016
stratta-v_1800x528-singledouble_ral_9016stratta-v-single-detailstratta-v_1800x528-double_ral_7016stratta-v-double-detail
£ 258.00 (£ 215.00 excl VAT) - starting price.
Height (mm)
Width (mm)
Depth
Finished In

Description

Tall, space saving and elegant: these are just some of the attributes that a mono-column radiator brings to the mix.The epitome of the radiator chic, mono-column designs offer a simple solution for those who want to modernise their homes. Inspired by many of the world's hip hotels, why not introduce a bit of hotel chic to your own abode. Use them in the kitchen, dining room or living room; these designs can be hung vertically to maximise space where it’s needed.
The STRATTA-V,  radiator is manufactured from "Flat" steel tubes and is free from sharp edges and corners. Positioned vertically only. STRATTA-V can be ordered with single or double tubes to achieve higher outputs.

Finishes: RAL 9016 (White)
Fuel type: C-central heating.
Availability: Delivery 3-7 days.

*Product does not include accessories and valves.

Looking for design inspiration? Why not take a look at our online brochure for more pictures of the STRATTA-V. Steel radiator, from the chic Mono-column radiator range.

See more details below.

STRATTA-V: Steel Radiator

          Output    Pipe Wall to
MODEL Tube Height Width Depth δ50w  Weight Ctrs Ctr
  (no) (mm) (mm) (mm) (w) (BTU's) (kg) (mm) (mm)
SINGLE
STR-SIN-1800 3 1800 224 71 402 1372 12 224* 41
  5 1800 376 71 670 2286 18 376* 41
  7 1800 528 71 938 3200 25 528* 41
  9 1800 680 71 1206  4115 31 680* 41
DOUBLE
STR-DBL-1800 6 1800 224 71 627 2139 20 224* 41
  10 1800 376 71 1045 3566 33 376* 41
  14 1800 528 71  1463  4992 46 528* 41
  18 1800 680 71 1881 6418 60 680* 41
δ60w = δ50w x 1.268               * Add
                Valves
